7
Figure 1-7 Audio/Video
Table 1-3 Audio/Video parameters
Channel
In the
list, select the channel that you want to configure the
settings for.
Smart Codec
Enable the smart codec function. This function can reduce the video bit
stream for non-important recorded video to maximize the storage
space.
Type
●
Main Stream: From the
drop-down list, select
,
, or
.
●
Sub Stream: This setting is not configurable.
Compression
In the
list, select the encode mode.
●
H.265: Main profile encoding. This setting is recommended.
●
H.264H: High profile encoding. Low bit stream with high definition.
●
H.264: General profile encoding.
●
H.264B: Baseline profile encoding. This setting requires higher bit
stream compared with other settings for the same definition.
Resolution
From the Resolution list, select a resolution for video output.
The maximum video resolution may vary model to model.
