Dahua DH-EPC PTZ Series User Manual

Explosion-proof Integrated PTZ & Camera-Instruction Manual
1
1. General
DH-EPC□-PTZ-□ Explosion-proof Integrated PTZ & Camera (hereinafter referred to as
camera) is a new generation of explosion-proof monitoring device, it adopts advanced
manufacturing process, with a mature quality management system as a guarantee, the product
quality, performance and appearance are in leading position. The product can be used in
flammable and explosive gas or flammable dust environment, to achieve the purpose of
monitoring the hazardous area.
The camera is designed and manufactured according to EN60079-0:2012+A11: 2013,
EN60079-1: 2014, EN60079-28: 2015, EN60079-31: 2014, IEC60079-0: 2011, IEC60079-1:
2014, IEC60079-28: 2015, IEC60079-31: 2013. The compact structure, small size make it
convenient for installation and maintenance. It’s applicable for petrol industry, chemical
industry, wharf, harbor, non-coal mine, aerospace industry, aircraft industry, military industry,
food processing industry and so on.
All associate technical document, drawings and samples of the camera are tested and certified
by China National Quality Supervision and Test Center for Explosion Protected Electrical
Apparatus (CQST), ATEX certification number: CE2614 CNEX 17 ATEX 0010 X and IECEx
certification number is IECEx CNEX 17.0012X.
1.1. Specification
DH - EPC□ -PTZ - □
□:
IR(with fill light) or None (without fill light)
□:
Camera model
Product code
Company code
Models:
With fill light:
DH-EPC230U-PTZ-IR，DH-EPC230UN-PTZ-IR ，DH-EPC245U-PTZ-IR ，
DH-EPC245UN-PTZ-IR ，DH-EPC430U-PTZ-IR ，DH-EPC430UN-PTZ-IR ，
DH-EPC240V-PTZ-IR ，DH-EPC240VN-PTZ-IR
Without fill light :
DH-EPC230U-PTZ，DH-EPC230UN-PTZ， DH-EPC245U-PTZ， DH-EPC245UN-PTZ，
DH-EPC430U-PTZ， DH-EPC430UN-PTZ，DH-EPC240V-PTZ，DH-EPC240VN-PTZ
Ingress protection level: IP68(1.2m/45min)
Ex marking:
2614
Ⅱ 2G Ex db op is Ⅱ C T6 Gb
