Dahua DH-XVR7216A-4KL-X User Manual

Local Configurations 305
Figure 5-279
5.20.8 Viewing Device Status
Not all models support this function.
You can view the information about device status.
Select Main Menu > ALARM > ABNORMALITY > Device. Step 1
The Device interface is displayed. See Figure 5-280.

Dahua DH-XVR7216A-4KL-X Specifications

General

Video Input Channels	16
Max Resolution	4K (3840 × 2160)
HDD Bays	2
HDD Interface	SATA
Max IP Camera Input	16
Operating Humidity	10% to 90% (non-condensing)
Video Output	1x HDMI, 1x VGA
Max HDD Capacity	10TB (per HDD)
Network Interface	1 RJ-45 port (10/100/1000 Mbps)
Audio Input/Output	1 × RCA Input, 1 × RCA Output
Compression	H.265+/H.265/H.264+/H.264
USB Interface	2 × USB 2.0
Operating Temperature	-10 °C to +55 °C (+14 °F to +131 °F)
Smart H.265+/H.265	Supported
