6
User’s Manual
Figure 2-2 Monitor adjustments
When adjusting the angle of the monitor, be sure not to touch or press the area of the screen.
The above figure is for reference only, and everything is subject to the actual adjustment function.
NOTE
DHI-LM30-E330CA
Rotation angle
±25°(±2.5°)
Tilting angle
-5.0°(±2.0°) ~ +20°(±2.0°)
Height adjustment
115mm(±5.0mm)
115mm
-5° 20°
