Dahua DHI-NVR5216-16P-4KS2E - Rear Panel; Product Series Rear Panel Identification

4
3 Rear Panel
Follow figures listed here for reference only. Please refer to the actual product for detailed information.
For SMART BOX series product, the front panel is shown as in Figure 3-1.
Figure 3-1
For SMART 1U series product, the front panel is shown as in Figure 3-2.
Figure 3-2
For mini 1U, compact 1U series product, the front panel is shown as in Figure 3-3.
Figure 3-3
For 1U series product, the front panel is shown as in Figure 4-4
Figure 3-4
Note
