Dahua IMOU User Manual

6
- If the Wi-Fi network changed or the indicator status goes wrong, reset the camera, and
then do step 5 to add it again.
Installing Camera 4
Note: Make sure the mounting surface is strong enough to hold at least three times of the device weight.
When installing the camera with mounting foam, make sure the mounting surface is smooth. Stick the
mounting foam on the camera pedestal, and then attach the pedestal on the mounting surface, press and
hold it for 10s.
Step 1 Drill screw holes on the mounting surface as the positioning map shows, and then put in the
expansion bolts.
Step 2 Attach the mounting plate to the mounting surface with the self-tapping screws.
Step 3 Attach the camera to the mounting plate, then power it up, and then, adjust the lens to the ideal
angle.
Positioning Map
Expansion Bolt
Camera
Self-tapping Screw
Mounting Surface
Mounting Plate

Dahua IMOU Specifications

General

Resolution	1080P (1920 x 1080)
Built-in Microphone and Speaker	Yes
Motion Detection	Yes
Configurable Region	Yes
Connectivity	Wi-Fi
Night Vision	Up to 10 meters (IR LED)
Audio	Two-way audio
Storage	Cloud
Image Sensor	CMOS
Lens	Fixed
Video Compression	H.265/H.264
Frame Rate	Up to 25fps
Wi-Fi	IEEE802.11b/g/n
Power Supply	DC 5V
Operating Conditions	-10°C to 45°C (14°F to 113°F)
Weather Resistance	IP66 (for outdoor models)
