Dahua IPC-HDB/HDBW3202 Series User Manual

14
Figure 2-7
Figure 2-8
Please refer to the following sheet for detailed information.
SN Definition
1
AC 24V power port. The middle pin is for GND.
2
DC 12V power port. The left is the negative end and the right
is the positive end.
3
External cable exit.
4
RJ45 network port.

Dahua IPC-HDB/HDBW3202 Series Specifications

General

Brand	Dahua
Model	IPC-HDB/HDBW3202 Series
Category	Security Camera
Language	English
