Dahua IPC-HDB3200C Series User Manual

4
Model
Parameter
IPC-HDB4100C
Series
IPC-HDB4200C
Series
IPC-HDB4300C
Series
System
Main
Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
SD card status, bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
1/2.8-inch CMOS
1/3-inch CMOS
Pixel
1280(H)*960(V)
1920(H)×1080(V)
2048(H)×1536(V)
Day/Night
Mode
Support day/night mode switch.
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
Off/BLC/WDR (1-100)/HLC(anti-flicker is outdoor and is valid only when
exposure mode is auto with range 1-100)
Electronic
Shutter
Manual/Auto
It ranges from 1/3 to 1/100000.
Video
Compression
Standard
H.264/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream
(1280*960@25fps)
Extra stream 1
(704*576@25fps)
Extra stream 2
(1280*720@8fps)
PAL:
Main stream
(1920*1080@25fps)
Extra stream 1
(704*576@25fps)
Extra stream 2
(1280*720@11fps)
PAL:
Main stream
(2048*1536@20fps)
Extra stream 1
(704*576@20fps)
Extra stream 2
(1280*720@1fps),
Main stream
(1920*1080@25fps)
Extra stream 1
(704*576@25fps)
Extra stream 2
(1280*720@11fps)
NTSC:
Main stream
(1280*960@30fps)
Extra stream 1
(704*480@30fps)
Extra stream 2
(1280*720@1fps)
NTSC:
Main stream
(1920*1080@30fps)
Extra stream 1
(704*480@30fps)
Extra stream 2
(1280*720@1fps)
NTSC:
Main stream
(2048*1536@20fps)
Extra stream 1
(704*480@20fps)
Extra stream 2
(1280*720@1fps),
Main stream
(1920*1080@30fps)
Extra stream 1
(704*480@30fps)
Extra stream 2
(1280*720@1fps)
Note:
Extra stream 2’s actual frame depends on max capacity set which can
be adjusted within its range.
Video Bit Rate
H.264H: 40Kbps-8192Kbps adjustable
MJPEG: 40Kbps~16384Kbps adjustable and bit rate is adjustable.
Support customized setup.
