Dahua IPC-HDB3200CP(N) Series User Manual

3
Motion Detect
396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The
6
th
level has the highest sensitivity)
Activation event: Video storage, image snapshot, log, email SMTP
function and etc.
Video
Video Loss
Activation event: Video storage, image snapshot, log, email SMTP
function and etc.
Alarm Input
2-channel input，1-channel output
Record
Priority
Manual> Video detect>Schedule
Record and
Backup
Local Storage
Support Micro SD card storage
Wire Network 1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network
Protocol
Standard HTTP, TCP/IP, IPv4/IPv6, ARP, IGMP, ICMP, RTSP, RTP,
UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP, NFS.
Platform
interface
Standard
ONVIF
Network
Remote
Operation
Monitor, system setup, log information, maintenance , upgrade and etc
Video Output
1-channel analog video output，BNC port, 9-pin port connection
AUX Interf
ace
Reset Built-in RESET button
Power Support DC12V and PoE
Power
Consumption
2.5W MAX
Working
Temperature
-10℃~+60℃
Working
Humidify
10%~90%
Dimensions(m
m)
¢110×54
Weight
0.25Kg
General Parameter
Installation Installed in the places such as wall or the ceiling
1.3.2 Factory Default Setup
Please refer to the following sheet for factory default setup information.
Default setup
Function
Setup Type
Item
IPC-HDB3200CP(N) Series
Brightness 50
Contrast 50
Hue 50
Saturation 50
Gain mode Auto
Gain limit 80
Exposure mode Auto
Scene mode Auto
Day/night mode Auto
BLC Off
Camera Setup Conditions
Mirror Disable
