Dahua IPC-HDW3200S User Manual

3
Network
Wire Network
1-ch 10/100 M Ethernet , RJ45 port
Network Protocol
HTTP, TCP/IP, ARP, RTSP, RTP,UDP, RTCP, SMTP, FTP, DHCP,
DNS, DDNS, PPPOE, IPv4/6, SNMP, UPNP, NTP
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Restore Default
Setup
Built-in Reset button
IR light
IR light 15M.
General Parameter
Power
DC12V power and PoE.
Warning！
Do not connect these two power supplying sources to the device
at the same time; it may result in device damage!
Power
Consumption
4.5W MAX
Working
Temperature
-20℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
Φ113×86
Weight
280g (Excluding box)
Installation
Ceiling and wall mount
Model
Parameter
IPC-HDW2200S
IPC-HDW3200S
IPC-HDW3300S
System
Main Processor
TI Davinci high performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
1/2.8-inch CMOS
1/3-inch CMOS
Pixel
1920(H)*1080(V)
2048(H)*1536(V)
Day/night
Support IR-CUT switch
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Manual/Auto
It ranges from 1/3 to 1/10000.
Video
Compression
Standard
H.264/H.264H/H.264B/MJPEG
Note: Some versions do not support H.264H.
Video Frame
Rate
PAL:
Main stream
(1920*1080@25fps),
extra stream
( 704*576@25fps)
PAL:
Main stream
(1920*1080@25fps),
extra stream
( 704*576@25fps)
PAL:
Main stream
(2048*1536@18fps)
extra stream
( 704*576@18fps),
Main stream
(1920*1080@25fps)
extra stream
