Dahua IPC-HDW3200S User Manual

4
( 704*576@25fps)
NTSC:
Main stream
(1920*1080@30fps),
extra stream
( 704*480@30fps)
NTSC:
Main stream
(1920*1080@30fps),
extra stream
( 704*480@30fps)
NTSC:
Main stream
(2048*1536@18fps)
extra stream
( 704*480@18fps),
Main stream
(1920*1080@25fps)
extra stream
( 704*480@30fps)
Video Bit Rate
H.264: 56Kbps-8192Kbps
MJPEG: adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.
Video
Information
Channel title, time title, motion detect, camera masking.
Lens
2.8mm, 3.6mm, 6mm,
8mm. Fixed focus.
3.6mm, 6mm, 8mm. Fixed focus.
Lens Interface
M12. Lens is the default accessories
Video
Motion Detect
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Activation event: video storage, image snapshot, log, email function
and etc.
Record
Record Priority
Manual >External alarm>Video detect>Schedule
Storage
Management
FTP storage
Network
Wire Network
1-ch 10/100 M Ethernet , RJ45 port
Network Protocol
HTTP, TCP/IP, ARP, RTSP, RTP,UDP, RTCP, SMTP, FTP, DHCP,
DNS, DDNS, PPPOE, IPv4/6, SNMP, UPNP, NTP
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
Restore Default
Setup
Built-in Reset button
IR light
IR light 20M.
IR light 25M.
IR light 20M.
General Parameter
Power
DC12V power and PoE.
Warning！
Do not connect these two power supplying sources to the device
at the same time; it may result in device damage!
Power
Consumption
4.5W MAX
Working
Temperature
-20℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
Φ113×86
Weight
280g (Excluding box)
Installation
Ceiling and wall mount
