HD IR Waterproof Network Camera Quick Start Guide
14
Figure 2-3
Figure 2-4
2.2 ONVIF NVR Configuration (Hikvison NVR for example)
2.2.1 camera connect to Hikvison NVR POE Ports.(NVR have POE Ports)
Note: Check your NVR preview and playback max resolution supported before configuration.
Step1:Log in the camera via browser. Adjust camera resolution is higher than NVR max preview
resolution, and Synchronize Time in accordance with your local time. See Pics Figure 2-5, Figure 2-6
Figure 2-5
DH-OEM Factory

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua IPC-HDW4431R-ZS and is the answer not in the manual?

Dahua IPC-HDW4431R-ZS Specifications

General IconGeneral
Scanning SystemProgressive
Max. ApertureF1.6
IR DistanceUp to 30 m
Bit Rate ControlCBR/VBR
Day/NightICR
White BalanceAuto/Manual
Gain ControlAuto/Manual
Noise Reduction3D DNR
Motion DetectionYes
Smart IRYes
DefogYes
Digital Zoom16x
FlipYes
MirrorYes
Privacy MaskingYes
InteroperabilityONVIF, PSIA, CGI
Streaming MethodUnicast / Multicast
Web ViewerIE, Chrome, Firefox, Safari
Smart PhoneiOS, Android
CertificationsCE, FCC, RoHS
Ingress ProtectionIP67
Vandal ResistanceIK10
CasingMetal
Image Sensor1/3" Progressive Scan CMOS
Effective Pixels2688(H) x1520(V)
Electronic Shutter Speed1/3s~1/100, 000s
S/N Ratio> 55 dB
IR On/Off ControlAuto
Video CompressionH.265/H.264
Resolution4MP (2688×1520)
Bit Rate32 Kbps to 8 Mbps
BLC ModeBLC/HLC
Region of InterestYes
Ethernet10/100 Mbps
ProtocolHTTP; HTTPS; TCP; UDP; RTSP; RTP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP; NTP; Bonjour; 802.1x
Edge StorageMicro SD card 128GB
Management SoftwareSmart PSS, DSS
Power SupplyDC12V, PoE
Operating Conditions-30 °C to +60 °C, Humidity 95% or less
Storage Conditions-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Net Weight0.5 kg
Lens TypeMotorized vari-focal
Streaming CapabilityTriple-streaming
