Dahua IPC-HF3500 Series User Manual

15
the external alarm
device.
NO
C
Alarm output port Alarm output port. To
output alarm signal to
the alarm device.
z NO: Normal open
alarm output end.
z C: Alarm output
public end.
G GND Alarm input ground
end.
A RS485_A port, control
external PTZ
B
RS485 port
RS485_B port, control
external PTZ
RX RS232_RX，RS232
receive end.
TX
RS232 port
RS232_TX，RS232
COM send out end.
G GND RS232 ground end
NA IR light port External IR light signal
control port.
RESET RESET button Restore factory default
setup.
When system is
running normally,
press the RESET
button for at least 5
seconds, system can
restore factory default
setup.
AUDIO OUT Audio output port Audio output 3.5mm
JACK port.
Output audio signal to
the passive device
such as earphone.
AUDIO IN Audio input port Audio input 3.5mm Input audio signal
