Dahua IPC-HFW1100S User Manual

3
Recor d and Backu p
Storage
Management
Support display network storage status
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network Protocol
Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,
SNMP.
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc.
IR light
IR distance 20~30m
General Parameter
Power
DC12V power, PoE.
DC12V
Power
Consumption
4.5W MAX
3.6W MAX
Working
Temperature
-30℃~+60℃
Working
Humidify
≤95%
Dimensions(mm)
70*66*155
Weight
620g
420g
Installation
Installation with the bracket.
Model
Parameter
IPC-
HFW2200S-V2
IPC-
HFW2205S-V2
IPC-
HFW2100S-V2
IPC-
HFW2105S-V2
System
Main Processor
High performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the
same time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
Bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/3-inch CMOS
Pixel
2048（H）*1536（V）
1280（H）*960（V）
Day/Night Mode
Support day/night mode switch.
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
On/Off
Exposure Mode
Auto/Manual
It ranges from 1/3 to 1/10000.
Video
Compression
Standard
H.264/H.264B/H.264H/MJPEG
Video Frame
Rate
PAL:
Main stream(1920*960@25fps)
extra stream(704*576@25fps),
PAL:
Main stream(1280*960@25fps)
extra stream(704*576@25fps),
NTSC:
Main stream(1920*960@30fps)
extra stream(704*480@30fps),
NTSC:
Main stream(1280*960@30fps)
extra stream(704*480@30fps),
