2 Front Panel and Rear Panel
The following front panel and rear panel figures are for reference only. The actual product shall
prevail.
2.1 Front Panel
2.1.1
NVR41/41-P/41-W/41-4KS2/41-P-4KS2/21-S2/21-P-S2/21-8P-S2/4
1-4KS2/41-P-4KS2/41-8P-4KS2/21-4KS2/21-P-4KS2/21-8P-4KS2
Series
The front panel is shown as in Figure 2-1.
Figure 2-1 Front panel
Table 2-1
No.
Name
Function
1
HDD status indicator light
The red light becomes on when HDD is
abnormal.
