Local Basic Operations 218
In the Connect Type list, select the connection protocol type.
Click , the IP Address interface is displayed.
In the Source IP box, enter the IP address (the machine that is
connected to the Device) that sends messages.
Select a character encoding mode.
In the Overlay list, Select Turn or ROLL.
Turn: Once the information is at 16 lines, system displays the
next page.
ROLL: Once the information is at 16 lines, system rolls one
line after another to delete the first line.
When the local preview mode is in 4-split, the turn/ROLL function
is based on 8 lines.
When the network is not working correctly and cannot be
recovered after the entered timeout limit, the POS information will
not display normally. After the network is recovered, the latest
POS information will be displayed.
Enter the time that how long you want to keep the POS
information displaying. For example, enter 5, the POS information
disappear from the screen after 5 seconds.
In the Font Size list, select Small, Medium, or Big as the text
size of POS information
In the color bar, click to select the color for the text size of POS
information.
Enable the POS Info function, the POS information displays in the
live view/WEB.
There is no line delimiter by default.
After set the line delimiter (HEX), the overlay information after the
delimiter is displayed in the new line. For example, the line
delimiter is F and the overlay information is 123156789, NVR
displays overlay information on the local preview interface and
Web as:
123
6789
Step 3 Click Apply to complete the settings.
4.9.2.1 Privacy Setup
Step 1 Click Setup
The Privacy interface is displayed. See Figure 4-189.
