Local Basic Operations 100
Figure 4-74
Refer to the following sheet for detailed information. See Table 4-19.
Table 4-19
Installation modes
Icon
Note
（Ceiling mount）
（Ground mount）
360°panorama original view
1 de-warp window+1 panorama stretching
2 panorama stretching view
1 360° panorama view+3 de-warp windows
1 360°panorama view+4 de-warp windows
4 de-warp windows+1 panorama stretching
1 360° panorama view+8 de-warp windows
（Wall mount）
360°panorama original view
Panorama stretching
1 panorama unfolding view+3 de-warp windows
