Dahua NVR5 NVR5864-I - CD-ROM Installation

Device Installation 27
Figure 3-16
3.5 CD-ROM Installation
Follow the steps listed below.
① Open top cover and then remove the
HDD bracket
② Take off the bottom of the HDD bracket and CD-ROM
bracket.
③ Fix the CD-ROM bracket at the HDD
bracket.
④ Install a pair of the CD-ROM bracket. Make sure the
reverse side is secure too.
