Local Basic Operations 226
Figure 4-198
Step 2 Click the LAN name that you want to view, for example, LAN1.
The system displays the information of data sending speed and receiving speed.
System displays LAN1 load by default.
Only one LAN load can be displayed at one time.
4.10.3.3 Network Test
You can test the network connection status between the Device and other devices.
Step 1 Select Main Menu > INFO > NETWORK > TEST.
The TEST interface is displayed. See Figure 4-199.
