Code: SD49425XB-HNR
IP SPEED DOME CAMERA OUTDOOR SD49425XB-HNR - 3.7 Mpx 4.8 ... 120 mm DAHUA
DELTA-OPTI Monika Matysiak; https://www.delta.poznan.pl
POL; 60-713 Poznań; Graniczna 10
e-mail: delta-opti@delta.poznan.pl; tel: +(48) 61 864 69 60
2021-07-04 SD49425XB-HNR 2/7
IP camera equipped with very good high resolution sensor. Due to above it is
perfect solution for surveillance systems requiring persons or vehicles recognition.
Built-in IR illuminator allows to operate at night conditions, and vari-focal lens with
wide range of view angle adjustment enables optimal set the view field of camera to
all conditions. The range of IR illumination according to the manufacturer data,
depends on outer conditions (visibility - air transparency, environment, wall colors
ie. scene reflectance).
The "Starlight" series cameras provide a clear color image even at very poor
lighting. PoE powering possibility, compatible with the 802.3at standard makes the
device more universal and easier to install.
For a few models of IP cameras working at ≥ 1920 x 1080 resolution we
recommend to use of network with 1Gb/s bandwidth.
Standard: TCP/IP
Sensor: 1/2.8 " STARVIS™ CMOS
Matrix size: 4 Mpx
Resolution:
2560 x 1440 - 3.7 Mpx ,
2048 x 1536 - 3 Mpx ,
1920 x 1080 - 1080p ,
1280 x 960 1.3 Mpx ,
1280 x 720 720p
Lens: 4.8 ... 120 mm
View angle:
• 60 ° ... 2.5 ° (manufacturer data)
• 53 ° ... 3.2 ° (our tests result)
Optical zoom: x 25
Digital zoom: x 16
Range of IR illumination: 100 m
Video output:
Preset rotation speed:
• 240 °/s (horizontal)
• 200 °/s (vertical)
Rotation speed (manual control):
• 0.1 °/s ... 200 °/s (horizontal)
• 0.1 °/s ... 120 °/s (vertical)
Horizontal rotation range: 360 ° - continuous
