SiUS121736EA SA Indoor Unit
Specifications 20
60 Hz, 208 - 230 V
Notes: 1.External static pressure is changeable in 13 stages (FDMQ09/12RVJU) or 11 stages (FDMQ15/18/
24RVJU) by remote controller. Refer to page 240 for details.
2.Air filter is not standard accessory, but please mount it in the duct system of the suction side.
Select its dust collection efficiency (gravity method) 50% or more.
Model
FDMQ24RVJU
Cooling Heating
Rated Capacity 24 kBtu/h Class
Casing Color —
Dimensions (H × W × D) in. (mm) 9-5/8 × 39-3/8 × 31-1/2 (245 × 1,000 × 800)
Coil
Type Cross Fin Coil
Rows × Stages × Fin per Inch 3 × 26 × 18
Face Area ft² (m²) 3-1/8 (0.288)
Fan
Type Sirocco Fan
Motor Output W 230
Airflow Rate
H / M / L
cfm
(m³/min)
798 / 678 / 558
(22.6 / 19.2 / 15.8)
798 / 678 / 558
(22.6 / 19.2 / 15.8)
External Static
Pressure 1
inH
2
O 0.20 (0.60 - 0.20)
Pa 50 (150 - 50)
Sound Pressure Level dB(A) 40 40
Sound Power Level dB(A) 54 54
Air Filter 2 —
Weight (Mass) Lbs (kg) 82 (37)
Piping
Connections
Liquid in. (mm) φ 1/4 (6.4) (Flare)
Gas in. (mm) φ 5/8 (15.9) (Flare)
Drain in. (mm) I.D. φ 1 (25) / O.D. φ 1-1/4 (32) (Flare)
Remote Controller
(Option)
Wired BRC1E73
Wireless BRC082A43
Drawing No. 3D112997D
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
To Next Page
