Daikin Altherma 3 GEO User Manual

4 Operation
User reference guide
21
EGSAH/X06+10(U)DA9W(G)
Daikin Altherma 3 GEO
4P569819-1A – 2019.10
4.8.3 Using and programming schedules
About schedules
Depending on your system layout and installer configuration,
schedules for multiple controls may be available.
You can:
▪ Select which schedules you currently want to use.
▪ Program your own schedules if the predefined schedules are not
satisfactory. The actions you can program are control specific.
Possible scheduling screens
Name and location Usage
[1.2] Room > Heating
schedule
Program the desired room temperature
in heating mode.
[1.3] Room > Cooling
schedule
Program the desired room temperature
in cooling mode.
[2.2] Main zone >
Heating schedule
Program the desired leaving water
temperature for the main zone in
heating mode.
[2.3] Main zone >
Cooling schedule
Program the desired leaving water
temperature for the main zone in
cooling mode.
[3.2] Additional zone >
Heating schedule
Program the desired leaving water
temperature for the additional zone in
heating mode.
[3.3] Additional zone >
Cooling schedule
Program the desired leaving water
temperature for the additional zone in
cooling mode.
[4.2] Space heating/
cooling > Operation
mode schedule
See "4.6.2Setting the space operation
mode"[416].
[5.5] Tank > Schedule Program the domestic hot water tank
temperature for your normal domestic
hot water needs:
▪ Comfort
▪ Eco
▪ Stop
[7.4.2] User settings >
Quiet > Schedule
Program when the unit has to use which
quiet mode level:
▪ Off
▪ Quiet
▪ More quiet
▪ Most quiet
[7.5.4] User settings >
Electricity price >
Schedule
Program when a certain electricity tariff
is valid.
Example of programming a schedule
See "4.8.4Schedule screen: Example"[421].
4.8.4 Schedule screen: Example
This example shows how to set a room temperature schedule in
heating mode for the main zone.
INFORMATION
The procedures to program other schedules are similar.
To program the schedule: overview
Example: You want to program the following schedule:
Mon
Sat
Wed
Fri
Thu
Tue
Sun
User defined 1
Prerequisite: The room temperature schedule is only available if
room thermostat control is active. If leaving water temperature
control is active, you can program the main zone schedule instead.
1 Go to the schedule.
2 (optional) Clear the content of the whole week schedule or the
content of a selected day schedule.
3 Program the schedule for Monday.
4 Copy the schedule to the other weekdays.
5 Program the schedule for Saturday and copy it to Sunday.
6 Give the schedule a name.
To go to the schedule:
1 Go to [1.1]: Room > Schedule.
2 Set scheduling to Yes.
3 Go to [1.2]: Room > Heating schedule.
To clear the content of the week schedule:
1 Select the name of the current schedule.
Mon
Sat
Wed
Fri
Thu
Tue
Sun
User defined 1
2 Select Delete.
Delete
Rename
Select
3 Select OK to confirm.
To clear the content of a day schedule:
1 Select the day of which you want to clear the
content. For example Friday
Mon
Sat
Wed
Fri
Thu
Tue
Sun
User defined 1
C
2 Select Delete.
Delete
Edit
Copy
3 Select OK to confirm.
