Removal of Outer Panels / Fan Motor Si00-772
6 Removal Procedure
6
Remove the 4 screws
and remove the fan
motor.
M4×16
7
Remove the 2 screws
and remove the fan
motor fixing frame.
Step
Procedure Points
Fan motor
(R3250)
(R3251)
Fan motor fixing frame
(R3252)
