Si04-751
Removal Procedure 1
Table of Contents
1. Removal of Air Filters..............................................................................2
2. Removal of Front Panel ..........................................................................4
3. Removal of Front Grille ...........................................................................5
4. Removal of Horizontal Blades / Vertical Blades......................................7
5. Removal of Electrical Box .....................................................................10
6. Removal of PCBs..................................................................................13
7. Removal of Drain Pan Unit / Swing Motor.............................................19
8. Removal of Fan Motor...........................................................................23
9. Removal of Indoor Heat Exchanger ......................................................25
10.Removal of Fan Rotor...........................................................................28
Note:
î
The illustrations may be slightly different depending on the model.
To Next Page
