COMPATIBILITY
Main Board Controller
BAG can only be used in conjunction with O.Y.L. Manufacturing produced Split type and
SQMB type air conditioner units with communication protocol N2.2 and N2.4 only.
Display Wired Panel
BAG can be used in conjunction with SLM8 (BRC51A), SQSLM8 (BRC51A64), SLM9,
SQSLM9 or SQLCD wired panel.
CONFIRMATION OF PARTS
The following parts are contained in the carton box together with this manual.
Please check to make sure that everything is included.
1. BMS Gateway (BAG)
2. Casing (top & bottom)
3. 5-way shield wire (1 meter) to/from mainboard controller.
4. Mounting screws
Procure the following parts locally:
1. Communication wires to/from SQMB mainboard controller and SQLCD wired panel.
Compatibility
Interface
SLM8 (BRC51A)/ SQSLM8
(BRC51A64)/ SLM9/ SQSLM9
SQLCD (with RS-485)
None of the interface above
Yes
Yes
No
Supported Configuration:
