Switch box
(field supply)
(Use optional accessory
KJB111A)
Small screws (M4×16)
Switch box for one unit
(with no cover)
84
28
(Installation pitch)
● Select fl at place for installation face as possible.
And, do not tighten the installation screws too much not to deform the lower case. ●
CAUTION
Install the upper case as original condition. 3-7
Align the upper case with tabs of the lower case (6 points), inset and install the upper case. ●
Install the wiring with care to prevent the pinch. ●
Peel off a protective seal which is attached on the upper case. ●
