OH08-1 Remote Controller (Wireless Type)
Control Systems 53
2
Operation Range
Split System
If the temperature or the humidity is beyond the following conditions, safety devices may work and the air
conditioner may not operate, or sometimes, water may drop from the indoor unit.
COOLING [
°
C]
HEATING [
°
C]
DB : Dry bulb temperature
WB: Wet bulb temperature
The setting temperature range of the remote controller is 16
°
C to 32
°
C.
VRV System
See the operation manual provided with the air conditioner.
Operation Procedure
Refer to figure 1 on page 49
z
Operating procedure varies with heat pump type and cooling only type. Contact your Daikin dealer to
confirm your system type.
z To protect the unit, turn on the main power switch 6 hours before operation.
z
If the main power supply is turned off during operation, operation will restart automatically after the
power turns back on again.
COOLING, HEATING, AUTOMATIC, FAN, AND PROGRAM DRY OPERATION
Operate in the following order.
z
AUTOMATIC OPERATION can be selected only by Heat pump split system or Heat recovery VRV
system.
z
For cooling only type, “COOLING”, and “FAN” and “DRY”operation are able to select.
(1) For Systems Without Cool / Heat Changeover Remote Control Switch
Refer to figure 1-1, 2 on page 49
OPERATION MODE SELECTOR
Press OPERATION MODE SELECTOR button several times and select the OPERATION MODE of
your choice as follows.
COOLING OPERATION...................................................“ ”
HEATING OPERATION....................................................“ ”
AUTOMATIC OPERATION ..............................................“ ”
z In this operation mode, COOL/HEAT changeover is automatically conducted.
FAN OPERATION ............................................................“ ”
DRY OPERATION............................................................“ ”
z
The function of this program is to decrease the humidity in your room with the minimum temperature
decrease.
z
The set point is the air temperature when starting operation by dry operation.
z
Micro computer automatically determines TEMPERATURE and FAN SPEED.
z
This system does not go into operation if the room temperature is below 16°C.
INDOOR
OUTDOOR
TEMPERATURE
TEMPERATURE HUMIDITY
DB 21 to 35
80% or
below
DB – 5 to 50
WB 14 to 25
INDOOR
TEMPERATURE
OUTDOOR
TEMPERATURE
DB 15 to 27
DB – 14 to 21
WB – 15 to 15.5
1
MODE
2.3 BRC7F634F / BRC7F635F
