Daikin BRP069A78 - About the Adapter; Basic Adapter Parameters; Adapter Compatibility

2 | About the adapter
Installer reference guide
4
BRP069A78
WLAN cartridge Heating
4P624190-1 – 2020.06
2 About the adapter
Wireless LAN adapter to connect the heat pump system to the Daikin Cloud via the
internet, allowing for control of the heat pump system with the Daikin Residential
Controller app.
2.1 Basic parameters
Parameter Value
Frequency range 2400MHz~2483.5MHz
Radio protocol IEEE 802.11b/g/n
Radio frequency channel 1~13
Output power 0dBm~18dBm
Effective radiated power 17dBm (11b) / 14dBm (11g) / 13dBm
(11n)
Power supply DC 3.3 V / 500 mA
2.2 Compatibility
Make sure the heat pump system is compatible for use with the adapter. For more
information, see the installer reference guide of the heat pump system.
