Specifications Si12-411A
40 Specifications
230V, 50Hz
Model
ATXS20CVMB(9) ATXS25CVMB(9)
Cooling Heating Cooling Heating
Rated Capacity 2.0kW Class 2.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 7.8 (275) 7.7 (272) 7.8 (275)
M 5.9 (208) 6.5 (230) 5.9 (208) 6.5 (230)
L 4.2 (148) 5.3 (187) 4.2 (148) 5.3 (187)
SL 3.6 (127) 4.6 (162) 3.6 (127) 4.6 (162)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimension (H×W×D) mm 258×834×325 258×834×325
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation Sound dBA
H38383838
M32333233
L25282528
SL 22 25 22 25
Sound Power dBA H 56 56 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D044251B 3D044252B
Model
ATXS35CVMB(9) ATXS50CVMB
Cooling Heating Cooling Heating
Rated Capacity 3.5kW Class 5.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.7 (272) 8.1 (286) 11.4 (402) 12.6 (445)
M 6.1 (215) 6.7 (237) 9.7 (342) 10.8 (381)
L 4.4 (155) 5.3 (187) 8.0 (282) 8.9 (314)
SL 3.8 (134) 4.6 (162) 7.1 (251) 7.7 (272)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 40
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.20
Power Consumption (Rated) W 40 40 40 45
Power Factor % 96.6 96.6 96.6 97.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 290×795×238
Packaged Dimension (H×W×D) mm 258×834×325 338×280×840
Weight kg 7.5 9
Gross Weight kg 11 13
Operation Sound dBA
H39394442
M33344038
L26293533
SL 23 26 32 30
Sound Power dBA H 57 57 63 60
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D044253B 3D044869
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
