Names of Parts
Indoor Unit
Receiver
Indoor unit ON/OFF switch
•Pressthisswitchoncetostartoperation.
Pressonceagaintostopit.
•Fortheoperationmodesetting,refertothefollowingtable.
Mode Temperature setting Airfl ow rate
COOL 22ºC AUTO
•Thisswitchcanbeusedwhentheremotecontrolleris
missingoroutofbatteries.
•Thislampisnotused.
OPERATION lamp (green)
TIMER lamp (orange)
Indoor temperature sensor
•Detectstheairtemperaturearound
theunit.
Air outlet
Air outlet grille ( eld supply)
Air inlet
Suction grille (sold separately)
•Thesuctiongrilleisnotincluded.
•Theappearanceofthesuctiongrillemay
differbetweendifferentmodels.
Outdoor Unit
 •Theappearanceoftheoutdoorunitmaydifferbetweendifferentmodels.
Earth terminal (inside)
Refrigerant pipes and
inter-unit wire
Air outlet
Air inlet
(back and side)
Model name
Drain hose
•Fordetailsonremotecontrolleroperation,refertotheoperationmanualincludedwiththeremotecontroller.
 Remote controller
Wireless type
Modelname BRC086A12
3
