Daikin DCH120 Series User Manual

SERVICING
33
PSIG
°F
PSIG
°F
PSIG
°F
PSIG
°F
PSIG
°F
PSIG
°F
12
-37.7
114.0
37.8
216.0
74.3
318.0
100.2
420.0
120.7
522.0
137.6
14
-34.7
116.0
38.7
218.0
74.9
320.0
100.7
422.0
121.0
524.0
137.9
16
-32.0
118.0
39.5
220.0
75.5
322.0
101.1
424.0
121.4
526.0
138.3
18
-29.4
120.0
40.5
222.0
76.1
324.0
101.6
426.0
121.7
528.0
138.6
20
-36.9
122.0
41.3
224.0
76.7
326.0
102.0
428.0
122.1
530.0
138.9
22
-24.5
124.0
42.2
226.0
77.2
328.0
102.4
430.0
122.5
532.0
139.2
24
-22.2
126.0
43.0
228.0
77.8
330.0
102.9
432.0
122.8
534.0
139.5
26
-20.0
128.0
43.8
230.0
78.4
332.0
103.3
434.0
123.2
536.0
139.8
28
-17.9
130.0
44.7
232.0
78.9
334.0
103.7
436.0
123.5
538.0
140.1
30
-15.8
132.0
45.5
234.0
79.5
336.0
104.2
438.0
123.9
540.0
140.4
32
-13.8
134.0
46.3
236.0
80.0
338.0
104.6
440.0
124.2
544.0
141.0
34
-11.9
136.0
47.1
238.0
80.6
340.0
105.1
442.0
124.6
548.0
141.6
36
-10.1
138.0
47.9
240.0
81.1
342.0
105.4
444.0
124.9
552.0
142.1
38
-8.3
140.0
48.7
242.0
81.6
344.0
105.8
446.0
125.3
556.0
142.7
40
-6.5
142.0
49.5
244.0
82.2
346.0
106.3
448.0
125.6
560.0
143.3
42
-4.5
144.0
50.3
246.0
82.7
348.0
106.6
450.0
126.0
564.0
143.9
44
-3.2
146.0
51.1
248.0
83.3
350.0
107.1
452.0
126.3
568.0
144.5
46
-1.6
148.0
51.8
250.0
83.8
352.0
107.5
454.0
126.6
572.0
145.0
48
0.0
150.0
52.5
252.0
84.3
354.0
107.9
456.0
127.0
576.0
145.6
50
1.5
152.0
53.3
254.0
84.8
356.0
108.3
458.0
127.3
580.0
146.2
52
3.0
154.0
54.0
256.0
85.4
358.0
108.8
460.0
127.7
584.0
146.7
54
4.5
156.0
54.8
258.0
85.9
360.0
109.2
462.0
128.0
588.0
147.3
56
5.9
158.0
55.5
260.0
86.4
362.0
109.6
464.0
128.3
592.0
147.9
58
7.3
160.0
56.2
262.0
86.9
364.0
110.0
466.0
128.7
596.0
148.4
60
8.6
162.0
57.0
264.0
87.4
366.0
110.4
468.0
129.0
600.0
149.0
62
10.0
164.0
57.7
266.0
87.9
368.0
110.8
470.0
129.3
604.0
149.5
64
11.3
166.0
58.4
268.0
88.4
370.0
111.2
472.0
129.7
608.0
150.1
66
12.6
168.0
59.0
270.0
88.9
372.0
111.6
474.0
130.0
612.0
150.6
68
13.8
170.0
59.8
272.0
89.4
374.0
112.0
476.0
130.3
616.0
151.2
70
15.1
172.0
60.5
274.0
89.9
376.0
112.4
478.0
130.7
620.0
151.7
72
16.3
174.0
61.1
276.0
90.4
378.0
112.6
480.0
131.0
624.0
152.3
74
17.5
176.0
61.8
278.0
90.9
380.0
113.1
482.0
131.3
628.0
152.8
76
18.7
178.0
62.5
280.0
91.4
382.0
113.5
484.0
131.6
632.0
153.4
78
19.8
180.0
63.1
282.0
91.9
384.0
113.9
486.0
132.0
636.0
153.9
80
21.0
182.0
63.8
284.0
92.4
386.0
114.3
488.0
132.3
640.0
154.5
82
22.1
184.0
64.5
286.0
92.8
388.0
114.7
490.0
132.6
644.0
155.0
84
23.2
186.0
65.1
288.0
93.3
390.0
115.0
492.0
132.9
648.0
155.5
86
24.3
188.0
65.8
290.0
93.8
392.0
115.5
494.0
133.3
652.0
156.1
88
25.4
190.0
66.4
292.0
94.3
394.0
115.8
496.0
133.6
656.0
156.6
90
26.4
192.0
67.0
294.0
94.8
396.0
116.2
498.0
133.9
660.0
157.1
92
27.4
194.0
67.7
296.0
95.2
398.0
116.6
500.0
134.0
664.0
157.7
94
28.5
196.0
68.3
298.0
95.7
400.0
117.0
502.0
134.5
668.0
158.2
96
29.5
198.0
68.9
300.0
96.2
402.0
117.3
504.0
134.8
672.0
158.7
98
30.5
200.0
69.5
302.0
96.6
404.0
117.7
506.0
135.2
676.0
159.2
100
31.2
202.0
70.1
304.0
97.1
406.0
118.1
508.0
135.5
680.0
159.8
102
32.2
204.0
70.7
306.0
97.5
408.0
118.5
510.0
135.8
684.0
160.3
104
33.2
206.0
71.4
308.0
98.0
410.0
118.8
512.0
136.1
688.0
160.8
106
34.1
208.0
72.0
310.0
98.4
412.0
119.2
514.0
136.4
692.0
161.3
108
35.1
210.0
72.6
312.0
98.9
414.0
119.6
516.0
136.7
696.0
161.8
110
35.5
212.0
73.2
314.0
99.3
416.0
119.9
518.0
137.0
112
36.9
214.0
73.8
316.0
99.7
418.0
120.3
520.0
137.3
*Based on ALLIED SIGNAL Data
Pressure vs. Temperature Chart
R-410A
