Daikin DM96VE - Page 34

34
SYSTEM OPERATION
DIP SWITCH SETTINGS
*NOT RECOMMENDED
**Factory Default
SINGLE STAGE COOLING^
Static
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
Tstat Call CFM CFM CFM CFM CFM CFM CFM CFM
Ylo
1328 1287 1249 1215 1170 1131 1085 1046
Y
1236 1189 1149 1101 1066 1017 969 928
Ylo
782 629 547 469 396 333 N/A N/A
Y
1328 1287 1249 1215 1170 1131 1085 1046
Ylo
782 629 547 469 396 333 N/A N/A
Y
1236 1189 1149 1101 1066 1017 969 928
Ylo
1328 1287 1249 1215 1170 1131 1085 1046
Y
947 899 842 786 730 666 610 557
Ylo
1328 1287 1249 1215 1170 1131 1085 1046
Y
1163 1115 1065 1018 979 928 878 832
Ylo
782 629 547 469 396 333 N/A N/A
Y
947 899 842 786 730 666 610 557
Ylo
1163 1115 1065 1018 979 928 878 832
Y
1236 1189 1149 1101 1066 1017 969 928
Ylo
1163 1115 1065 1018 979 928 878 832
Y
782 629 547 469 396 333 N/A N/A
Static
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
Tstat Call CFM CFM CFM CFM CFM CFM CFM CFM
**OFF OFF OFF
G
947 899 842 786 730 666 610 557
ON OFF OFF
G
1163 1115 1065 1018 979 928 878 832
ON ON OFF
G
782 629 547 469 396 333 290 251
OFF ON OFF
G
1328 1287 1249 1215 1170 1131 1085 1046
OFF OFF ON
G
1236 1189 1149 1101 1066 1017 969 928
OFF ON ON
G
947 899 842 786 730 666 610 557
ON OFF ON
G
947 899 842 786 730 666 610 557
ON ON ON
G
947 899 842 786 730 666 610 557
Static
0.6 0.7 0.8
Tstat Call CFM Rise CFM Rise CFM Rise CFM Rise CFM Rise CFM CFM CFM
W1
947 39 899 41 842 44 786 47 730 51 666 610 557
W2
1163 45 1115 47 1065 50 1018 52 979 54 928 878 832
W1
782 47 629 NA 547 N/A 469 N/A 396 N/A N/A N/A N/A
W2
1163 45 1115 47 1065 50 1018 52 979 54 928 878 832
W1
782 47 629 NA 547 N/A 469 N/A 396 N/A N/A N/A N/A
W2
1328 40 1287 41 1249 42 1215 43 1170 45 1131 1085 1046
W1
1328 40 1287 41 1249 42 1215 43 1170 45 1131 1085 1046
W2
1236 43 1189 44 1149 46 1101 48 1066 50 1017 969 928
DM96VE0603BNBA - COOLING
DIP Switches
S1-1 S1-2 S1-3
**OFF OFF OFF
ON OFF OFF
ON ON OFF
OFF ON OFF^
0.5
OFF OFF ON
OFF ON ON
ON OFF ON^
ON ON ON^
DM96VE0603BNBA - CONTINUOUS FAN
DIP Switches
S2-2 S2-3 S2-4
**OFF OFF
ON OFF
*ON ON
OFF ON
DM96VE0603BNBA - HEATING
DIP Switches
S1-4 S2-1
0.1 0.2 0.3 0.4
