Daikin DP5HM - Page 19

19

Speed Tap Switch 1 Switch 2
A OFF OFF
B ON OFF
C OFF ON
D ON ON
Electric Heat
DIP Switch Settings
Thermostat Switch 3 Switch 4
Single-Stage N/A ON
Two- Stage N/A OFF
DIP Switch Settings for
Single & Two-Stage Thermostat
Speed Tap Switch 5 Switch 6
A OFF OFF
B ON OFF
C OFF ON
D ON ON
Cooling/HP DIP Switch Settings
CFM Switch 7 Switch 8
Plus 10% ON OFF
Normal OFF OFF
Minus 10% OFF ON
Speed Tap Adjustment
Through DIP Switches


MODEL
SPEED
TAP
SWITCH
1
SWITCH
2
ELECTRIC
HEAT (CFM)
A Off Off
1050
B On Off 950
C Off On 825
D On On 700
A Off Off
1250
B On Off
1100
C Off On
1000
D On On
800
A Off Off
1250
B On Off 1100
C Off On 1000
D On On 800
A
Off Off 1800
B
On Off 1700
C Off On
1400
D On On 1225
A
Off Off
1800
B
On Off 1700
C
Off On 1400
D
On On 1225
DP5HM24
DP5HM30
DP5HM42
DP5HM48
DP5HM36


MO DEL
SPEED
TAP
SWITCH
5
SWITCH
6
COOLING/HP
CFM
A Off Off
1050
B On Off 950
C Off On 825
D On On 700
A Off Off
1250
B On Off 1100
C
Off On 1000
D
On On 800
A Off Off
1250
B
On Off 1100
C
Off On 1000
D
On On 800
A
Off Off 1800
B
On Off 1700
C Off On
1400
D On On 1225
A Off Off
1800
B On Off 1700
C
Off On 1400
D
On On 1225
DPHM36
DP5HM24
DP5HM30
DP5HM42
DP5HM48



1 2 3     
 ON    ON   ON
 ON    ON   
 ON    ON  ON 
 ON ON   ON ON ON 
        ON
