Daikin EWAA006D2V3P-H Operation Manual

Table of contents
Operation manual
2
EWAA004~008D + EWYA004~008D
Packaged air-cooled water chillers
and packaged air to water heat pumps
4P688015-1C – 2022.09
Table of contents
1 About this document 2
2 User safety instructions 3
2.1 General...................................................................................... 3
2.2 Instructions for safe operation ................................................... 3
3 About the system 4
3.1 Components in a typical system layout ..................................... 4
4 Quick guide 4
4.1 User permission level ................................................................ 4
4.2 Space heating/cooling ............................................................... 5
5 Operation 6
5.1 User interface: Overview ........................................................... 6
5.2 Menu structure: Overview user settings .................................... 8
5.3 Possible screens: Overview ...................................................... 9
5.3.1 Home screen............................................................... 9
5.3.2 Main menu screen ...................................................... 9
5.3.3 Setpoint screen ........................................................... 10
5.3.4 Detailed screen with values ........................................ 10
5.4 Turning operation ON or OFF ................................................... 11
5.4.1 Visual indication .......................................................... 11
5.4.2 To turn ON or OFF...................................................... 11
5.5 Reading out information ............................................................ 11
5.6 Space heating/cooling control ................................................... 11
5.6.1 Setting the space operation mode .............................. 11
5.6.2 To change the desired room temperature................... 12
5.6.3 To change the desired leaving water temperature...... 12
5.7 Schedule screen: Example........................................................ 12
5.8 Weather-dependent curve......................................................... 14
5.8.1 What is a weather-dependent curve? ......................... 14
5.8.2 2-points curve ............................................................. 15
5.8.3 Slope-offset curve ....................................................... 15
5.8.4 Using weather-dependent curves ............................... 15
6 Energy saving tips 16
7 Maintenance and service 16
7.1 Overview: Maintenance and service ......................................... 16
8 Troubleshooting 17
8.1 To display the help text in case of a malfunction....................... 17
8.2 To check the malfunction history............................................... 17
8.3 Symptom: You are feeling too cold (hot) in your living room..... 17
8.4 Symptom: Unit failure ................................................................ 17
8.5 Symptom: The system is making gurgling noises after
commissioning........................................................................... 18
9 Disposal 18
10 Installer settings: Tables to be filled in by
installer 18
10.1 Configuration wizard.................................................................. 18
10.2 Settings menu ........................................................................... 18
1 About this document
Thank you for purchasing this product. Please:
▪ Read the documentation carefully before operating the user
interface to ensure the best possible performance.
▪ Request the installer to inform you about the settings that he used
to configure your system. Check if he has filled in the installer
settings tables. If NOT, request him to do so.
▪ Keep the documentation for future reference.
Target audience
Endusers
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪ General safety precautions:
▪ Safety instructions that you must read before installing
▪ Format: Paper (in the box of the outdoor unit)
▪ Operation manual:
▪ Quick guide for basic usage
▪ Format: Paper (in the box of the outdoor unit)
▪ User reference guide:
▪ Detailed step-by-step instructions and background information
for basic and advanced usage
▪ Format: Digital files on https://www.daikin.eu. Use the search
function to find your model.
▪ Installation manual:
▪ Installation instructions
▪ Format: Paper (in the box of the outdoor unit)
▪ Installer reference guide:
▪ Preparation of the installation, good practices, reference
data,…
▪ Format: Digital files on https://www.daikin.eu. Use the search
function to find your model.
▪ Addendum book for optional equipment:
▪ Additional info about how to install optional equipment
▪ Format: Paper (in the box of the outdoor unit) + Digital files on
https://www.daikin.eu. Use the search function to find your
model.
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your installer.
The original documentation is written in English. All other languages
are translations.
ONECTA app
If set up by your installer, you can use the
ONECTA app to control and monitor the status
of your system. For more information, see:
http://www.onlinecontroller.daikineurope.com/
Breadcrumbs
Breadcrumbs (example: [4.3]) help you to locate where you are in
the menu structure of the user interface.
1 To enable the breadcrumbs: In the home screen or
main menu screen, press the help button. The
breadcrumbs appear in the top left corner of the
screen.
2 To disable the breadcrumbs: Press the help button
again.
This document also mentions these breadcrumbs. Example:
1 Go to [4.3]: Space heating/cooling > Operation
range.
This means:
