Daikin FCA71AV16 - Outdoor Unit Unpacking and Packing; Outdoor Unit Unpacking

a)
b)
c)
Strap
Starp Cutter
Cardboard box
❶
• Cut all the straps (a) from the unit
using strap cutter(b) as shown in
figure.
❷
❸
• Remove the bottom skid(d) with EPS by
pulling the unit up, then remove the
polythene product cover by pulling it up
❹
14. Unpacking & Packing of the Outdoor Unit
14-1 Unpacking
 • Remove the cardboard box(c)
from the unit after opening it and
pulling it up as shown in figure.
d)
Bottom Skid
