Engineering Data - R410A MODEL
MODEL
INDOOR UNIT
FCN30FV1 FCN30FV1 FCN35FV1
FCN40FV1
OUTDOOR UNIT
RN28CV1 RN30CV1 RN35DV1
RN40DY1
NOMINAL COOLING CAPACITY
Btu/h
28000 30000 36000
42000
W
8210 8790 10550
12310
NOMINAL TOTAL INPUT POWER (COOLING) W
2836 2930 3770
4110
NOMINAL RUNNING CURRENT (COOLING) A
13.30 13.6 16.7
6.57
EER W/W
2.89 3.00 2.80
3.00
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg
1.80 2.10 1.90
2.70
POWER SOURCE V/Ph/Hz 220 - 240 /1/50 380 - 415 / 3 / 50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE 8 WAYS AIR DISCHARGE
OPERATION WIRED OR WIRELESS MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH CFM
890 890 1030
1120
MEDIUM CFM
760 760 870
1030
LOW CFM
620 620 730
890
SUPER LOW CFM
490 490 580
760
SOUND PRESSURE LEVEL (H/M/L/Q) dBA
41 / 38 / 35 / 32 41 / 38 / 35 / 32 46 / 41 / 37 / 34
48 / 45 / 41 / 37
UNIT DIMENSION [PANEL]
HxWxD
mm
246 X 840 X 840
[305 X 950 X 950]
246 X 840 X 840
[305 X 950 X 950]
288 X 840 X 840
[347 X 950 X 950]
288 X 840 X 840
[347 X 950 X 950]
PACKING DIMENSION [PANEL]
HxWxD
mm 324 X 916 X 916 [147X1008X970] 370 X 916 X 916 [147X1008X970]
UNIT WEIGHT (UNIT + PANEL) kg
22 + 5 22 + 5 25 + 5
25 + 5
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE F
RATED INPUT POWER W
155 186
200
RATED RUNNING CURRENT A
0.68 0.81
0.88
MOTOR MAX OUTPUT W
55 82
105
POLES 6
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.44 0.53
0.53
ROW
2 2 2
2
FIN PER INCH
20
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW CFM
1712 1712 3000
3150
SOUND PRESSURE LEVEL dBA
54 56 58
60
UNIT DIMENSION
HxWxD
mm
753 X 855 X 328 753 X 855 X 328 852 x 1030 x 400
852 x 1030 x 400
PACKING DIMENSION
HxWxD
mm
793 x 990 x 415 793 x 990 x 415 1010 X 1180 X 514
1010 x 1180 x 514
UNIT WEIGHT kg
57 57 71
95
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm
9.52 9.52 9.52
9.52
GAS mm
15.88 15.88 15.88
15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE PERMANENT SPLIT CAPACITOR
INDEX OF PROTECTION (IP)
IP23 IP24 IP54
IP44
INSULATION GRADE
F F F
F
RATED INPUT POWER W
124 123 223
276
RATED RUNNING CURRENT A
0.54 0.54 0.98
1.34
MOTOR OUTPUT W
66 70 145
145
POLES
6 6 8
8
COMPRESS
OR
TYPE ROTARY SCROLL
OIL TYPE FV50S
MOBILE EAL ARCTIC
22C
OIL AMOUNT cm
3
1130 700 1300
1951
RATED INPUT POWER W
2499 2652 3361
3634
RATED RUNNING CURRENT A
10.98 12.38 14.91
5.83
LOCKED ROTOR AMP. A
63 64.0 68.0
51.5
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7 7 7 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.61 0.61 0.87
0.85
ROW
2 2 1
2
FIN PER INCH
18
CASING COLOUR IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING
INDOOR: 27°C DB/ 19°C WB
OUTDOOR: 35°C DB/ 24°C WB
