Read Before Operation
Names of Parts
Indoor Unit
Air filter
(inside suction grille)
Indoor unit
Remote controller
(wired type)
Suction grille
Flap (1 on each side)
Model name
(inside suction grille)
Dischargedair
Inletair
Air outlet
•Theappearanceoftheremotecontrollermaydifferbetweendifferentmodels.
Wired type Wireless type
Decoration panel Remote controller
•Fordetailsonremotecontrolleroperation,refertothe
operationmanualincludedwiththeremotecontroller.
Outdoor Unit
•Theappearanceoftheoutdoorunitmaydifferbetweendifferentmodels.
Earth terminal (inside)
Refrigerant pipes and
inter-unit wire
Air outlet
Air inlet (back and side)
Model name
Drain hose
