Performance Data
Model: FFY20CXV1 - RY18CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
340
16°C
21°C 4.98 3.29 1.40 4.80 3.21 1.51 4.62 3.12 1.64 4.44 3.03 1.78 4.08 2.82 1.93 3.76 2.65 2.12
24°C 4.99 3.94 1.40 4.81 3.85 1.51 4.63 3.76 1.64 4.44 3.67 1.78 4.08 3.43 1.93 3.78 3.23 2.12
27°C 5.02 4.47 1.40 4.86 4.37 1.51 4.69 4.26 1.64 4.51 4.15 1.78 4.16 3.87 1.93 3.87 3.63 2.13
30°C 5.18 5.18 1.41 5.03 5.03 1.52 4.88 4.88 1.65 4.72 4.72 1.79 4.38 4.38 1.95 4.09 4.09 2.15
19°C
24°C 5.49 3.07 1.42 5.30 2.99 1.54 5.10 2.92 1.67 4.90 2.83 1.81 4.51 2.64 1.96 4.16 2.48 2.16
27°C 5.49 3.52 1.42 5.30 3.44 1.54 5.11 3.36 1.67 4.91 3.28 1.81 4.51 3.06 1.96 4.17 2.90 2.16
30°C 5.50 4.34 1.42 5.31 4.25 1.54 5.13 4.15 1.67 4.93 4.05 1.81 4.54 3.79 1.96 4.21 3.59 2.16
33°C 5.57 5.57 1.42 5.39 5.39 1.54 5.21 5.21 1.67 5.03 5.03 1.82 4.66 4.66 1.97 4.36 4.36 2.18
22°C
27°C 6.04 3.01 1.45 5.83 2.93 1.57 5.62 2.86 1.70 5.40 2.78 1.84 4.97 2.59 2.00 4.60 2.44 2.20
30°C 6.04 3.67 1.45 5.83 3.59 1.57 5.62 3.51 1.70 5.40 3.42 1.84 4.97 3.20 2.00 4.60 3.04 2.20
33°C 6.05 4.28 1.45 5.84 4.20 1.57 5.62 4.12 1.70 5.41 4.03 1.84 4.97 3.78 2.00 4.61 3.59 2.20
36°C 6.07 4.85 1.45 5.87 4.76 1.57 5.66 4.66 1.70 5.46 4.55 1.85 5.03 4.27 2.00 4.68 4.05 2.21
410
16°C
21°C 5.18 3.43 1.41 4.99 3.34 1.53 4.80 3.26 1.65 4.61 3.16 1.79 4.23 2.95 1.94 3.90 2.77 2.14
24°C 5.20 4.17 1.41 5.01 4.07 1.53 4.82 3.97 1.65 4.63 3.87 1.79 4.25 3.61 1.94 3.93 3.41 2.14
27°C 5.26 4.73 1.41 5.08 4.62 1.53 4.91 4.50 1.66 4.73 4.37 1.80 4.37 4.06 1.95 4.07 3.80 2.16
30°C 5.48 5.48 1.42 5.32 5.32 1.54 5.16 5.16 1.67 4.99 4.99 1.82 4.62 4.62 1.97 4.32 4.32 2.18
19°C
24°C 5.71 3.25 1.43 5.50 3.17 1.55 5.30 3.08 1.68 5.08 3.00 1.82 4.67 2.79 1.98 4.31 2.63 2.18
27°C 5.72 3.74 1.43 5.51 3.66 1.55 5.31 3.58 1.68 5.09 3.49 1.82 4.68 3.26 1.98 4.33 3.09 2.18
30°C 5.74 4.61 1.44 5.54 4.51 1.55 5.35 4.41 1.68 5.14 4.31 1.83 4.73 4.03 1.98 4.39 3.80 2.19
33°C 5.84 5.84 1.44 5.66 5.66 1.56 5.48 5.48 1.69 5.30 5.30 1.84 4.91 4.91 2.00 4.59 4.59 2.21
22°C
27°C 6.27 3.18 1.46 6.05 3.10 1.58 5.82 3.03 1.71 5.59 2.94 1.86 5.14 2.75 2.02 4.75 2.59 2.22
30°C 6.28 3.90 1.46 6.06 3.82 1.58 5.83 3.74 1.72 5.60 3.65 1.86 5.15 3.42 2.02 4.76 3.24 2.22
33°C 6.29 4.57 1.46 6.07 4.48 1.58 5.85 4.39 1.72 5.62 4.30 1.86 5.17 4.03 2.02 4.79 3.83 2.22
36°C 6.33 5.17 1.46 6.12 5.07 1.59 5.91 4.96 1.72 5.70 4.85 1.87 5.25 4.54 2.03 4.90 4.28 2.24
450
16°C
21°C 5.37 3.58 1.42 5.17 3.49 1.54 4.98 3.40 1.67 4.77 3.30 1.81 4.37 3.08 1.96 4.03 2.90 2.16
24°C 5.40 4.35 1.42 5.20 4.25 1.54 5.01 4.14 1.67 4.81 4.04 1.81 4.41 3.77 1.96 4.08 3.55 2.16
27°C 5.49 4.99 1.43 5.31 4.86 1.55 5.13 4.72 1.67 4.94 4.58 1.82 4.57 4.24 1.97 4.26 3.96 2.18
30°C 5.76 5.76 1.44 5.59 5.59 1.56 5.42 5.42 1.69 5.24 5.24 1.84 4.85 4.85 2.00 4.53 4.53 2.20
19°C
24°C 5.91 3.44 1.45 5.70 3.35 1.56 5.48 3.26 1.70 5.26 3.18 1.84 4.83 2.96 1.99 4.46 2.79 2.20
27°C 5.93 3.97 1.45 5.72 3.88 1.57 5.50 3.79 1.70 5.28 3.70 1.84 4.85 3.46 2.00 4.48 3.27 2.20
30°C 5.98 4.89 1.45 5.77 4.78 1.57 5.56 4.68 1.70 5.35 4.56 1.84 4.92 4.26 2.00 4.57 4.01 2.21
33°C 6.11 6.11 1.46 5.93 5.93 1.58 5.75 5.75 1.71 5.56 5.56 1.86 5.15 5.15 2.02 4.81 4.81 2.23
22°C
27°C 6.49 3.36 1.47 6.26 3.29 1.60 6.02 3.20 1.73 5.78 3.12 1.87 5.31 2.91 2.03 4.91 2.75 2.24
30°C 6.50 4.14 1.47 6.27 4.06 1.60 6.03 3.98 1.73 5.79 3.89 1.88 5.32 3.64 2.03 4.92 3.45 2.24
33°C 6.52 4.86 1.48 6.30 4.77 1.60 6.07 4.67 1.73 5.83 4.57 1.88 5.36 4.28 2.04 4.97 4.06 2.25
36°C 6.58 5.48 1.48 6.38 5.38 1.60 6.16 5.26 1.74 5.93 5.13 1.89 5.48 4.79 2.05 5.11 4.51 2.26
Model: FFY20CXV1 - RY18CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 3.258 3.258 3.688 3.688 3.831 3.831 5.406 5.406 6.265 6.265 6.695 6.695 7.124 7.124
17°C 3.173 3.173 3.395 3.395 3.738 3.738 5.400 5.400 6.138 6.138 6.562 6.562 6.985 6.985
19°C 3.088 3.088 3.102 3.102 3.644 3.644 5.393 5.393 6.011 6.011 6.428 6.428 6.846 6.846
21°C 3.002 3.002 2.982 2.982 3.551 3.551 5.293 5.293 5.883 5.883 6.295 6.295 6.707 6.707
23°C 2.917 2.917 3.035 3.035 3.458 3.458 5.100 5.100 5.756 5.756 6.162 6.162 6.567 6.567
25°C 2.831 2.831 3.087 3.087 3.364 3.364 4.907 4.907 5.629 5.629 6.029 6.029 6.428 6.428
27°C 2.746 2.746 3.140 3.140 3.271 3.271 4.714 4.714 5.502 5.502 5.895 5.895 6.289 6.289
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
