5 Operation
User reference guide
5
FNA25~60A2VEB(9)
Split system air conditioners
4P543324-3 – 2018.08
WARNING
NEVER let the indoor unit or the user interface get wet. It
may cause an electric shock or a fire.
WARNING
Do NOT place objects in direct proximity of the outdoor unit
and do NOT let leaves and other debris accumulate
around the unit. Leaves are a hotbed for small animals
which can enter the unit. Once in the unit, such animals
can cause malfunctions, smoke or fire when making
contact with electrical parts.
WARNING
Avoid placing the user interface in a place where it can be
splashed with water. Water entering the machine may
cause an electric leak or may damage the internal
electronic parts.
WARNING
This unit contains electrical and hot parts.
WARNING
Before operating the unit, be sure the installation has been
carried out correctly by an installer.
WARNING
NEVER use a flammable spray such as hair spray, lacquer
or paint near the unit. It may cause a fire.
CAUTION
Do NOT touch the heat exchanger fins. These fins are
sharp and could result in cutting injuries.
WARNING
Do NOT place a flammable spray bottle near the air
conditioner and do NOT use sprays. Doing so may result in
a fire.
WARNING
Do NOT keep flammable materials inside the unit. They
may cause an explosion or a fire.
CAUTION
It is not good for your health to expose your body to the air
flow for a long time.
CAUTION
To avoid oxygen deficiency, ventilate the room sufficiently
if equipment with burner is used together with the system.
CAUTION
Do NOT operate the system when using a room
fumigation-type insecticide. Chemicals could collect in the
unit, and endanger the health of people who are
hypersensitive to chemicals.
CAUTION
NEVER expose little children, plants or animals directly to
the airflow.
NOTICE
Do NOT place the user interface in a place exposed to
direct sunlight. The LCD display may get discoloured or fail
to display the data.
NOTICE
Do NOT place items which might be damaged by moisture
under the indoor unit. Condensation may form if the
humidity is above 80%, if the drain outlet is blocked or the
filter is polluted.
NOTICE
Arrange the drain hose to ensure smooth drainage.
Incomplete drainage may cause the building, furniture, etc.
to get wet.
NOTICE
Be sure to turn on the power 6 hours before operation in
order to have power running to the crankcase heater and
to protect the compressor.
This operation manual is for the following systems with standard
control. Before initiating operation, contact your dealer for the
operation that corresponds to your system type and mark. If your
installation has a customised control system, ask your dealer for the
operation that corresponds to your system.
5 Operation
5.1 Operation range
Use the system in the following temperature and humidity ranges for
safe and effective operation.
Outdoor units using R410A refrigerant
Outdoor unit Cooling Heating
RR71~125 –15~46°CDB —
18~37°CDB
12~28°CWB
—
RQ71~125 –5~46°CDB –9~21°CDB
–10~15°CWB
18~37°CDB
12~28°CWB
10~27°CDB
RXS25~60 –10~46°CDB –15~24°CDB
–16~18°CWB
18~32°CDB 10~30°CDB
3MXS40~68
4MXS68~80
5MXS90
–10~46°CDB –15~24°CDB
–16~18°CWB
18~32°CDB 10~30°CDB
RZQG71~140 –15~50°CDB –19~21°CDB
–20~15.5°CWB
18~37°CDB
12~28°CWB
10~27°CDB
RZQSG71~140 –15~46°CDB –14~21°CDB
–15~15.5°CWB
20~37°CDB
14~28°CWB
10~27°CDB
RZQ200~250 –5~46°CDB –14~21°CDB
–15~15°CWB
20~37°CDB
14~28°CWB
10~27°CDB
Indoor humidity ≤80%
(a)
