Daikin FTKB18A - Outdoor Unit Dimensions

English
1-3
Outdoor Unit [RXB/RKB]
Dimension
Model
ABCDEFGHIJKLMNO
18 33-11/16
(855)
24-3/4
(628)
12-15/16
(328)
20-1/2
(520)
7-1/16
(179)
1-13/16
(46)
4
(101)
4-7/16
(113)
23-3/4
(603)
4-15/16
(126)
6-7/16
(164)
9/16
(15)
1-5/16
(34)
15/16
(23)
14-1/4
(362)
24 33-11/16
(855)
28-3/4
(730)
12-15/16
(328)
20-1/2
(520)
7-1/16
(179)
1-13/16
(46)
4
(101)
4-7/16
(113)
23-3/4
(603)
4-15/16
(126)
6-7/16
(164)
9/16
(15)
1-5/16
(34)
15/16
(23)
14-1/4
(362)
Dimension
Model
ABCDEFGHIJKLMNOPQ
09/12 21-5/8
(550)
25-15/16
(658)
2
(51)
7/16
(11)
10-3/4
(273)
5/8
(16)
9/16
(14)
18-1/2
(470)
3-3/4
(96)
3-11/16
(93)
3-11/16
(94)
2-3/8
(60)
9/16
(14)
5-1/4
(133)
5/16
(8)
3/8
(10)
11-3/4
(299)
Dimension
Model
PQRST
18 2-7/8
(73)
2-15/16
(75)
5/16
(8)
2-5/8
(67)
1/4
(7)
24 2-7/8
(73)
2-15/16
(75)
5/16
(8)
2-5/8
(67)
1/4
(7)
EF
B
HI
N
Q
KL
G
A
M
CD
J
5/64
(2)
OP
B
A
O
N
P
Q
DM
IJJ
K
L
FE
C
GH
L
S
R
T
All dimensions are in Inch (mm)
All dimensions are in Inch (mm)
1/8
(3)
1 IM-5WMYJ(R)-0617(0)-DAIKIN USA3 31 IM-5WMYJ(R)-0617(0)-DAIKIN USA3 3 10/12/17 10:30:58 AM10/12/17 10:30:58 AM
