Indoor Unit Si04-306
148 Removal Procedure
7. Remove the swing motor
for vertical blades.
1
Release the swing axis
on the right side.

Releasing the swing axis
2
Loosen the two screws
and detach the swing
motor assembly.
3
Loosen the two screws
and remove the swing
motor.

Six claws hold the assembly.
Step
Procedure Points
