Specifications Si04-306
24 Specifications
220V, 60Hz
Notes:

MAX. interunit piping length: 30m

MAX. interunit height difference: 20m

Amount of additional charge for piping length exceeding 10m: 20g/m(50/60 class), 50g/m(71 class)

The data are based on the conditions shown in the table below.
Model
Indoor Units FTXD50BVMT FTXD60BVMT
Outdoor Units
RXD50BVMT RXD60BVMT
Cooling Heating Cooling Heating
Capacity (Min.~Max.)
kW 0.9~5.9 0.9~8.0 0.9~6.5 0.9~8.1
kcal/h 775~5,070 775~6,880 775~5,590 775~6,970
Moisture Removal L/h 2.9 — 3.9 —
Running Current A 8.00 9.10 9.60 9.60
Power Consumption (Min.~Max.) W 450~2,300 450~2,800 460~2,710 460~2,600
Power Factor % 99.4 98.9 99.4 99.4
COP W/W 2.86 3.28 2.79 3.39
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Unit FTXD50BVMT FTXD60BVMT
Front Panel Color White White
Air Flow Rate m³/min (cfm)
H 15.4 (545) 16.1 (569) 16.2 (572) 17.1 (605)
M 12.9 (456) 13.7 (485) 13.6 (480) 14.8 (521)
L 10.8 (383) 11.5 (406) 11.4 (402) 12.5 (443)
SL 9.6 (339) 10.2 (359) 10.2 (358) 10.9 (385)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current A 0.19 0.19 0.21 0.21
Power Consumption W 40 40 45 45
Power Factor % 95.7 95.7 97.4 97.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 44/40/35/32 42/38/33/30 45/41/36/33 44/40/35/32
Outdoor Unit RXD50BVMT RXD60BVMT
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC32UXD 2YC32UXD
Motor Output W 1,500 1,500
Refrigerant
Oil
Model SE50P SE50P
Charge L 0.65 0.65
Refrigerant
Model R22 R22
Charge kg 1.25 1.60
Air Flow Rate m³/min (cfm)
H 42.8 (1,511) 40.7 (1,437) 46.3 (1,634) 44.2 (1,560)
L 40.7 (1,437) 40.7 (1,437) 42.9 (1,514) 44.2 (1,560)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current A 7.81 8.91 9.39 9.39
Power Consumption W 1,710 1,940 2,055 2,055
Power Factor % 99.5 99.0 99.5 99.5
Starting Current A 9.1 9.6
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 784×960×390 784×960×390
Weight kg 49 53
Gross Weight kg 54 57
Operation
Sound
H/L dBA 47/44 48/45 49/46 49/46
Drawing No. 3D040808A 3D040809A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 21°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
