Specifications ED041204
8 Split Type Air Conditioners FTK(X)S-L Series
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTKS50LVMA FTKS60LVMA
Outdoor Unit RKS50LVMA RKS60LVMA
Capacity
Rated (Min. ~ Max.)
kW 5.0 (1.7 ~ 6.0) 6.0 (1.7 ~ 6.7)
Btu/h 17,100 (5,800 ~ 20,500) 20,500 (5,800 ~ 22,900)
kcal/h 4,300 (1,460 ~ 5,160) 5,160 (1,460 ~ 5,760)
Moisture Removal L/h 2.9 3.9
Running Current (Rated) A 6.1 - 5.8 - 5.6 / 6.1 - 5.8 7.8 - 7.4 - 7.1 / 7.8 - 7.4
Power Consumption
Rated (Min. ~ Max.)
W 1,320 (440 ~ 1,920) 1,690 (440 ~ 2,230)
Power Factor % 98.4 - 99.0 - 98.2 / 98.4 - 99.0 98.5 - 99.3 - 99.2 / 98.5 - 99.3
EER (Cooling)
Rated (Min. ~ Max.)
W/W 3.79 (3.86 ~ 3.13) 3.55 (3.86 ~ 3.00)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 12.7 φ 12.7
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 30 30
Max. lnterunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTKS50LVMA FTKS60LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
18.3 (646) 19.2 (678)
M 14.9 (526) 15.5 (547)
L 11.6 (410) 11.9 (420)
SL 10.8 (381) 10.7 (378)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.30 - 0.29 - 0.28 / 0.30 - 0.29 0.48 - 0.46 - 0.45 / 0.48 - 0.46
Power Consumption (Rated) W 38 - 38 - 38 / 38 - 38 60 - 60 - 60 / 60 - 60
Power Factor % 57.6 - 57.0 - 56.5 / 57.6 - 57.0 56.8 - 56.7 - 55.6 / 56.8 - 56.7
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 248 340 × 1,050 × 248
Packaged Dimensions (H × W × D) mm 331 × 1,160 × 429 331 × 1,160 × 429
Weight (Mass) kg 14 14
Gross Weight (Gross Mass) kg 20 21
Sound Pressure
Level
H / M / L / SL dB(A) 46 / 40 / 35 / 32 48 / 42 / 36 / 33
Sound Power
Level
HdB 62 64
Outdoor Unit RKS50LVMA RKS60LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant Oil
Type FVC50K FVC50K
Charge L 0.650 0.650
Refrigerant
Type R-410A R-410A
Charge kg 1.8 1.8
Airflow Rate
H
m³/min
(cfm)
48.5 (1,713) 50.4 (1,780)
SL 41.6 (1,469) 42.3 (1,494)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 5.9 - 5.6 - 5.4 / 5.9 - 5.6 7.5 - 7.1 - 6.8 / 7.5 - 7.1
Power Consumption (Rated) W 1,282 - 1,282 - 1,282 / 1,282 - 1,282 1,630 - 1,630 - 1,630 / 1,630 - 1,630
Power Factor % 98.8 - 99.5 - 98.9 / 98.8 - 99.5 98.8 - 99.8 - 99.9 / 98.8 - 99.8
Starting Current A 6.1 10
Dimensions (H × W × D) mm 735 × 825 × 300 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 792 × 960 × 390 792 × 960 × 390
Weight (Mass) kg 46 46
Gross Weight (Gross Mass) kg 52 52
Sound Pressure
Level
H / SL dB(A) 47 / 44 49 / 46
Sound Power
Level
HdB 61 63
Drawing No. 3D075828A 3D075829
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
7.5 m
