Split Type Air Conditioners FTK(X)S-L Series 9
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTKS71LVMA
Outdoor Unit RKS71LVMA
Capacity
Rated (Min. ~ Max.)
kW 7.1 (2.3 ~ 8.5)
Btu/h 24,200 (7,800 ~ 29,000)
kcal/h 6,110 (1,980 ~ 7,310)
Moisture Removal L/h 4.5
Running Current (Rated) A 9.7 - 9.3 - 8.9 / 9.7 - 9.3
Power Consumption
Rated (Min. ~ Max.)
W 2,080 (570 ~ 3,060)
Power Factor % 97.5 - 97.2 - 97.4 / 97.5 - 97.2
EER (Cooling)
Rated (Min. ~ Max.)
W/W 3.41 (4.04 ~ 2.78)
Piping
Connections
Liquid mm φ 9.5
Gas mm φ 15.9
Drain mm φ 16.0
Heat Insulation Both Liquid and Gas Pipes
Max. lnterunit Piping Length m 30
Max. lnterunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of Refrigerant g/m 50
Indoor Unit FTKS71LVMA
Front Panel Colour White
Airflow Rate
H
m³/min
(cfm)
21.1 (745)
M 16.9 (597)
L 12.7 (448)
SL 11.5 (406)
Fan
Type Cross Flow Fan
Motor Output W 48
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.68 - 0.65 - 0.62 / 0.68 - 0.65
Power Consumption (Rated) W 82 - 82 - 82 / 82 - 82
Power Factor % 54.8 - 54.8 - 55.1 / 54.8 - 54.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 248
Packaged Dimensions (H × W × D) mm 331 × 1,160 × 429
Weight (Mass) kg 14
Gross Weight (Gross Mass) kg 21
Sound Pressure
Level
H / M / L / SL dB(A) 51 / 44 / 37 / 34
Sound Power
Level
HdB 67
Outdoor Unit RKS71LVMA
Casing Colour Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63BXD
Motor Output W 1,920
Refrigerant Oil
Type FVC50K
Charge L 0.750
Refrigerant
Type R-410A
Charge kg 2.3
Airflow Rate
H
m³/min
(cfm)
55.8 (1,970)
SL 46.0 (1,624)
Fan
Type Propeller
Motor Output W 66
Running Current (Rated) A 9.3 - 8.9 - 8.5 / 9.3 - 8.9
Power Consumption (Rated) W 1,998 - 1,998 - 1,998 / 1,998 - 1,998
Power Factor % 97.7 - 97.6 - 97.9 / 97.7 - 97.6
Starting Current A 9.7
Dimensions (H × W × D) mm 770 × 900 × 320
Packaged Dimensions (H × W × D) mm 900 × 925 × 390
Weight (Mass) kg 71
Gross Weight (Gross Mass) kg 79
Sound Pressure
Level
H / SL dB(A) 52 / 49
Sound Power
Level
HdB 66
Drawing No. 3D075830
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
7.5 m
