Specifications ED041204
10 Split Type Air Conditioners FTK(X)S-L Series
3.2 Heat Pump
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS20LVMA FTXS25LVMA
Outdoor Unit
RXS20LVMA RXS25LVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.0 (1.3 ~ 2.8) 2.7 (1.3 ~ 4.3) 2.5 (1.3 ~ 3.2) 3.4 (1.3 ~ 4.7)
Btu/h 6,800 (4,400 ~ 9,600) 9,200 (4,400 ~ 14,700) 8,500 (4,400 ~ 10,900) 11,600 (4,400 ~ 16,000)
kcal/h 1,720 (1,120 ~ 2,410) 2,320 (1,120 ~ 3,700) 2,150 (1,120 ~ 2,750) 2,920 (1,120 ~ 4,040)
Moisture Removal L/h 0.9 — 1.2 —
Running Current (Rated) A 2.6 - 2.5 - 2.4 / 2.6 - 2.5 3.5 - 3.4 - 3.2 / 3.5 - 3.4 3.1 - 3.0 - 2.9 / 3.1 - 3.0 4.0 - 3.8 - 3.7 / 4.0 - 3.8
Power Consumption
Rated (Min. ~ Max.)
W 450 (320 ~ 910) 610 (310 ~ 1,360) 540 (320 ~ 770) 700 (310 ~ 1,170)
Power Factor %
78.7 - 78.3 - 78.1 /
78.7 - 78.3
79.2 - 78.0 - 79.4 /
79.2 - 78.0
79.2 - 78.3 - 77.6 /
79.2 - 78.3
79.5 - 80.1 - 78.8 /
79.5 - 80.1
EER (Cooling) / COP (Heating)
Rated (Min. ~ Max.)
W/W 4.44 (4.06 ~ 3.08) 4.43 (4.19 ~ 3.16) 4.63 (4.06 ~ 4.16) 4.86 (4.19 ~ 4.02)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ 9.5
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 20
Max. Interunit Height Difference m 15 15
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTXS20LVMA FTXS25LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
9.7 (343) 10.5 (371) 10.6 (374) 11.5 (406)
M 7.7 (272) 8.5 (300) 8.1 (286) 9.3 (328)
L 5.6 (198) 6.7 (237) 5.7 (201) 7.2 (254)
SL 4.1 (145) 5.6 (198) 4.4 (155) 6.4 (226)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A
0.09 - 0.08 - 0.08 /
0.09 - 0.08
0.10 - 0.10 - 0.09 /
0.10 - 0.10
0.10 - 0.09 - 0.09 /
0.10 - 0.09
0.13 - 0.13 - 0.12 /
0.13 - 0.13
Power Consumption (Rated) W 18 - 18 - 18 / 18 - 18 21 - 21 - 21 / 21 - 21 20 - 20 - 20 / 20 - 20 28 - 28 - 28 / 28 - 28
Power Factor %
90.9 - 97.8 - 93.8 /
90.9 - 97.8
95.5 - 91.3 - 97.2 /
95.5 - 91.3
90.9 - 96.6 - 92.6 /
90.9 - 96.6
97.9 - 93.6 - 97.2 /
97.9 - 93.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 9 10
Gross Weight (Gross Mass) kg 13 13
Sound Pressure
Level
H / M / L / SL dB(A) 38 / 32 / 25 / 22 39 / 34 / 28 / 25 40 / 32 / 25 / 22 40 / 34 / 28 / 25
Sound Power
Level
HdB54555656
Outdoor Unit RXS20LVMA RXS25LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 600 600
Refrigerant Oil
Type FVC50K FVC50K
Charge L 0.375 0.375
Refrigerant
Type R-410A R-410A
Charge kg 0.8 1.2
Airflow Rate
H
m³/min
(cfm)
36.2 (1,278) 32.6 (1,151) 33.5 (1,183) 30.2 (1,066)
SL 32.7 (1,155) 27.8 (982) 30.1 (1,063) 25.6 (904)
Fan
Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 2.5 - 2.4 - 2.3 / 2.5 - 2.4 3.4 - 3.3 - 3.1 / 3.4 - 3.3 3.0 - 2.9 - 2.8 / 3.0 - 2.9 3.8 - 3.6 - 3.6 / 3.8 - 3.6
Power Consumption (Rated) W 432 - 432 - 432 / 432 - 432 589 - 589 - 589 / 589 - 589 520 - 520 - 520 / 520 - 520 672 - 672 - 672 / 672 - 672
Power Factor %
78.5 - 78.3 - 78.3 /
78.5 - 78.3
78.7 - 77.6 - 79.2 /
78.7 - 77.6
78.8 - 78.0 - 77.4 /
78.8 - 78.0
80.4 - 81.2 - 77.8 /
80.4 - 81.2
Starting Current A 3.5 4.0
Dimensions (H × W × D) mm 550 × 765 × 285 550 × 765 × 285
Packaged Dimensions (H × W × D) mm 589 × 882 × 363 589 × 882 × 363
Weight (Mass) kg 31 34
Gross Weight (Gross Mass) kg 35 38
Sound Pressure
Level
H / SL dB(A) 46 / 43 47 / 44 47 / 43 48 / 44
Sound Power
Level
HdB60616162
Drawing No. 3D075848 3D075849A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
7.5 m
