ED041204 Specifications
Split Type Air Conditioners FTK(X)S-L Series 11
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXS35LVMA FTXS46LVMA
Outdoor Unit
RXS35LVMA RXS46LVMA
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 3.5 (1.4 ~ 4.0) 4.0 (1.4 ~ 5.2) 4.6 (1.7 ~ 5.3) 5.1 (1.7 ~ 6.8)
Btu/h 11,900 (4,800 ~ 13,600) 13,600 (4,800 ~ 17,700) 15,700 (5,800 ~ 18,100) 17,400 (5,800 ~ 23,200)
kcal/h 3,010 (1,200 ~ 3,440) 3,440 (1,200 ~ 4,470) 3,960 (1,460 ~ 4,560) 4,390 (1,460 ~ 5,850)
Moisture Removal L/h 1.9 — 2.9 —
Running Current (Rated) A 4.4 - 4.2 - 4.0 / 4.4 - 4.2 4.1 - 4.0 - 3.8 / 4.1 - 4.0 5.8 - 5.5 - 5.3 / 5.8 - 5.5 6.3 - 6.0 - 5.8 / 6.3 - 6.0
Power Consumption
Rated (Min. ~ Max.)
W 910 (350 ~ 1,160) 880 (340 ~ 1,320) 1,250 (440 ~ 1,760) 1,370 (400 ~ 2,160)
Power Factor %
94.0 - 94.2 - 94.8 /
94.0 - 94.2
97.6 - 95.7 - 96.5 /
97.6 - 95.7
98.0 - 98.8 - 98.3 /
98.0 - 98.8
98.8 - 99.3 - 98.4 /
98.8 - 99.3
EER (Cooling) / COP (Heating)
Rated (Min. ~ Max.)
W/W 3.85 (4.00 ~ 3.45) 4.55 (4.12 ~ 3.94) 3.68 (3.86 ~ 3.01) 3.72 (4.25 ~ 3.15)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 9.5 φ12.7
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 20 30
Max. Interunit Height Difference m 15 20
Chargeless m 10 10
Amount of Additional Charge of Refrigerant g/m 20 20
Indoor Unit FTXS35LVMA FTXS46LVMA
Front Panel Colour White White
Airflow Rate
H
m³/min
(cfm)
11.3 (399) 12.0 (424) 12.2 (431) 12.9 (455)
M 8.6 (304) 9.8 (346) 10.6 (374) 10.8 (381)
L 5.9 (208) 7.7 (272) 9.0 (318) 8.7 (307)
SL 4.6 (162) 6.6 (233) 7.9 (279) 7.7 (272)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downwards Right, Left, Horizontal, Downwards
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A
0.12 - 0.12 - 0.11 /
0.12 - 0.12
0.14 - 0.14 - 0.13 /
0.14 - 0.14
0.15 - 0.14 - 0.14 /
0.15 - 0.14
0.16 - 0.16 - 0.15 /
0.16 - 0.16
Power Consumption (Rated) W 26 - 26 - 26 / 26 - 26 30 - 30 - 30 / 30 - 30 32 - 32 - 32 / 32 - 32 35 - 35 - 35 / 35 - 35
Power Factor %
98.5 - 94.2 - 98.5 /
98.5 - 94.2
97.4 - 93.2 - 96.2 /
97.4 - 93.2
97.0 - 99.4 - 95.2 /
97.0 - 99.4
99.4 - 95.1 - 97.2 /
99.4 - 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 274 × 870 × 366 274 × 870 × 366
Weight (Mass) kg 10 10
Gross Weight (Gross Mass) kg 13 13
Sound Pressure
Level
H / M / L / SL dB(A) 42 / 34 / 26 / 23 42 / 36 / 29 / 26 44 / 40 / 35 / 32 42 / 38 / 33 / 30
Sound Power
Level
HdB58586058
Outdoor Unit RXS35LVMA RXS46LVMA
Casing Colour Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 2YC36BXD
Motor Output W 600 1,100
Refrigerant Oil
Type FVC50K FVC50K
Charge L 0.375 0.650
Refrigerant
Type R-410A R-410A
Charge kg 1.2 1.7
Airflow Rate
H
m³/min
(cfm)
36.0 (1,271) 30.2 (1,066) 48.5 (1,713) 39.8 (1,405)
SL 30.1 (1,063) 25.6 (904) 41.6 (1,469) 37.0 (1,306)
Fan
Type Propeller Propeller
Motor Output W 33 53
Running Current (Rated) A
4.3 - 4.1 - 3.9 /
4.3 - 4.1
4.0 - 3.9 - 3.7 /
4.0 - 3.9
5.6 - 5.4 - 5.2 /
5.6 - 5.4
6.1 - 5.9 - 5.7 /
6.1 - 5.9
Power Consumption (Rated) W
884 - 884 - 884 /
884 - 884
850 - 850 - 850 /
850 - 850
1,218 - 1,218 - 1,218 /
1,218 - 1,218
1,335 - 1,335 - 1,335 /
1,335 - 1,335
Power Factor %
93.4 - 93.7 - 94.4 /
93.4 - 93.7
96.6 - 94.8 - 95.7 /
96.6 - 94.8
98.9 - 98.1 - 97.6 /
98.9 - 98.1
99.5 - 98.4 - 97.6 /
99.5 - 98.4
Starting Current A 4.4 6.3
Dimensions (H × W × D) mm 550 × 765 × 285 735 × 825 × 300
Packaged Dimensions (H × W × D) mm 589 × 882 × 363 792 × 960 × 390
Weight (Mass) kg 34 46
Gross Weight (Gross Mass) kg 38 52
Sound Pressure
Level
H / SL dB(A) 49 / 44 49 / 45 47 / 44 48 / 45
Sound Power
Level
HdB63636162
Drawing No. 3D075850A 3D075851
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
7.5 m
