READ BEFORE OPERATION READ BEFORE OPERATION
 Open the front panel
Backside of the front panel
Fixing tab
Panel support plate
Streamer unit (inside)
Prevents mold and allergens
with the decomposition power
of the streamer discharge.
Page 18
 Outdoor Unit
For RKY25/35
Outside air temperature sensor: (Back)
• It senses the ambient temperature around the unit.
Air outlet
Earth terminal:
• It is inside of this cover.
Drain hose
Air inlet:
• Back RKY25
• Back and side RKY35
Refrigerant piping and
inter-unit cable
For RKY50/60/71
Outside air temperature sensor: (Back)
• It senses the ambient temperature around the unit.
Air outlet
Refrigerant piping and
inter-unit cable
Drain hose
Air inlet:
(Back and side)
Earth terminal:
• It is inside of this cover.
Names of Parts
6
