Si041352ED Swing Motors
Removal Procedure 21
5 Remove the 2 screws.
6 Remove the swing
motor for vertical blade.
7 Disconnect the
connector.
Step Procedure Points
(R9556)
(R9557)
Swing motor for
vertical blade
(R18720)
