1-2
OUTLINE DIMENSION
INDOOR UNIT FTXC20/25/35/50
REAR
785
RIGHT
TOP VIEW
BOTTOM
INDOOR UNIT ON-OFF
SWITCH
SIGNAL RECEIVER
ROOM TEMPERATURE
THERMISTOR
LEFT
UP DOWN
FLAP
FRONT VIEW
SIDE VIEW
250
288
MODEL
NAME PLATE
INDOOR UNIT FTXC60/71
REAR
1005
RIGHT
TOP VIEW
BOTTOM
INDOOR UNIT ON-OFF
SWITCH
SIGNAL RECEIVER
ROOM TEMPERATURE
THERMISTOR
LEFT
UP DOWN
FLAP
FRONT VIEW
SIDE VIEW
288
297
MODEL
NAME
PLATE
BOTTOM
BOTTOM
REAR
REAR
All dimensions are in mm
All dimensions are in mm
