SiBE04-101
Table of Contents i
Inverter Pair
FTXD-J, FLX-J / RXD-J
Series
Wall Mounted Type
Heat Pump
Indoor Unit
FTXD50JV1B
FTXD60JV1B
FTXD71JV1B
Outdoor Unit
RXD50JV1B
RXD60JV1B
RXD71JV1B
Floor / Ceiling
Suspended Dual Type
Heat Pump
Indoor Unit
FLX50JV1B
FLX60JV1B
Outdoor Unit
RXD50JV1B
RXD60JV1B
SiBE04-101.book Page i Monday, October 15, 2001 3:08 PM
